Transmission Electron Microscope (TEM CM 200)

TEM is not working. Samples are not accepted till further notice.
    Kindly download Analysis Request Form and Safety Data sheet and submit the hardcopy of filled sheet along with your sample

  Instrument Details

Make : PHILIPS
Model : CM 200
Specification : Operating voltages : 20-200kv Resolution :2.4 Ao


  Applications

     Materials Science/Metallugy
     biological Science
     Nanotechnology
     Ceramics
     Pharmaceuticals
     Semiconductors


  Contact Us

         Contact : 022-25764694
         Email Id : temlab@iitb.ac.in


  Working Principles


     TEM images are formed using transmitted electrons (instead of the visible light) which can produce magnification details up to 1,000,000x with resolution better than 10 Ao. The images can be resolved over a fluorescent screen or a photographic film. Further more the analysis of the X-ray produced by the interaction between the accelerated electrons with the sample allows detemining the elemental composition of the sample with high spatial resolution.


  User Instructions
External Users( Other than IIT Bombay):
       1. A requisition letter addressed to Head, SAIF along with a printout of electronic fund transfer (NEFT) proof should be sent by post or submitted in
       person to SAIF office, IIT Bombay, Powai, Mumbai-400076.
       2. Once we receive the requisition letter and advance payment, your appointment will be scheduled as per the queue.
       3. The user will be informed about the appointment date and time by e-mail.
       4. The sample can be loaded on carbon coated copper grid or can be made in disc form, 3mm diameter, with a thinned (electron transparency)
      central area.
       5. It is most desirable that the user is present in the TEM lab at the time of appointment for better utilization of the facility.
       6. Please send or submit sample details form along with the requisition letter and advance payment Click here to download sample details form
       7. If the information is incomplete the samples will be sent back to the user.
       8. Before proceeding further, please review How to Use Facility and Payment Procedure for more information.

Internal (IIT Bombay) Users:
       1. The user should register online.
       2. An appointment will be given as per the queue and the user will be informed by an email.
       3. The new user is requested to contact TEM Lab before registration.
